Design

• Double walled
• Stand-alone unit
• with cleaner pump
• Electric rinse aid supply
• Door opening with safety system
• 2 Wash arms for effective cleaning
• With rinse arms
• Automatic start when door is closed
• electronic control panel with LCD display
• Easy to clean

Quality

• Corpus made of high quality stainless steel AISI 304
• Very robust device

Rinsing process

• easy handling: 4 programms
•
• rinsing programm I:
• washing cycle: 60 seconds
• Baskets/h: 60 pieces
•
• rinsing programm II:
• washing cycle: 120 seconds
• Baskets/h: 30 pieces
•
• rinsing programm III:
• washing cycle: 180 seconds
• Baskets/h: 20 pieces
•
• rinsing programm IV:
• washing cycle: 480 seconds
• Baskets/h: 8 pieces

Technology

• wash tank with filter sytem (easy and quick cleaning)
• rotating, non-congestive wash and rinse arms
• One pump for rinse aid andwashing-up liquid

Product benefits

• Pumps empty automatically after the wash cycle
• excellent cleaning results
• high washing performance
• all internal components can be easily removed for cleaning
• Excellent cleaning results

Connection:

• Output: 11,42 kW
• Electric connection: 400 Volt / 3+N / 50 Hz

Dimensions

• External dimensions W x D x H: 685 x 720 x 1690 / 1860 mm

scope of supply

• Universal basket
• Tray basket
• Plate rack
• Cutlery basket with 4 compartments,

Guidelines

• Produced according hygiene and safety requirements
• EU, CE and the product has been produced in accordance

Note

• Information on supply voltage in the user manual
• hot water connection recommended
• Please note that this appliance is only suitable for chlorine-free cleaner.
• For optimum rinsing, we recommend that you regularly descale the appliance and its components!
• If you have installed a de-scaler upstream of the cartridge, please note that the cartridge must be regenerated after approx. litres of water flow. The actual maximum flow rate is determined by the water hardness.
• Detailed instructions can be found under the tab 'Download' and 'Video'.
