Technical details

SAP Code    00014776
Net Width [mm]    1200
Net Depth [mm]    730
Net Height [mm]    300
Net Weight [kg]    114.00
Gross Width [mm]    1260
Gross depth [mm]    820
Gross Height [mm]    512
Gross Weight [kg]    128.00
Device type    Electric unit
Construction type of device    Table top
Power electric [kW]    15.000
Loading    400 V / 3N - 50 Hz
Protection of controls    IP24
Exterior color of the device    Stainless steel
Material    AISI 304 top plate and cladding
Indicators    operation
Worktop type    Molded - comfortable cleaning maintenance
Worktop material    AISI 304
Worktop Thickness [mm]    1.50
Power consumption of the zone 1 [kW]    2,5
Power consumption of the zone 2 [kW]    2,5
Power consumption of the zone 3 [kW]    2,5
Power consumption of the zone 4 [kW]    2,5
Power consumption of the zone 5 [kW]    2,5
Power consumption of the zone 6 [kW]    2,5
Maximum device temperature [°C]    400
Minimum device temperature [°C]    50
Service accessibility    Trough the frontal panel
Number of burners/hot plates    6
Type of electric cooking zones    Squared
Solid top dimensions [mm x mm]    300 x 300
Cross-section of conductors CU [mm²]    4
